Product Specification
| Performance properties | Strain range7) | ±1500μɛ | |
Accuracy (guaranteed)1) | <0.50% FS3) | ||
Accuracy (typical)1) | <0.23% FS3) | ||
Precision (guaranteed)2) | <0.25% FS3) | ||
Precision (typical)2) | <0.15% FS3) | ||
| Strain sensitivity | 1.2pm/µɛ | ||
| Operating Temperature range | -20°C to +60°C | ||
| Ingress Protection rating | IP 67 | ||
| Physical properties | Housing material | Construction steel, 1.0439 (B500B) | |
Anchoring distance | Not applicable | ||
Dimensions (without cable)4) | Ø8-12mm x 250-1000mm | ||
Weight (without cable) | 150-850g | ||
Cable type | 3mm armored cable | ||
| Cable length5) | 1mtr | ||
| Cable Bend Radius (dynamic) | 40mm | ||
| Cable Bend Radius (static) | 30mm | ||
Connector type6) | FC/APC | ||
| Mounting method | Embedding | ||
| Packaging | Cardboard box – dimensions depending on the final configuration. | ||
| Quality Statement | The sensor is compliant with IEC 61757-1-1:2020, IEC 61757-2-1:2021 and IEC 61757:2018 All sensors are 100% tested and calibrated at SYLEX. Sensor is manufactured according to ISO 9001:2015 and ISO 14001:2015 | ||
Notes:
- 1) Accuracy is established for each individual sensor under laboratory conditions and it includes hysteresis, non-linearity and repeatability of the sensor.
- 2) Precision is established on a batch basis and it includes hysteresis, non-linearity, repeatability and reproducibility of the sensor.
- 3) FS: full scale range
- 4) For further dimensions details see the product drawing
- 5) Cable length is extendable on request
- 6) Other connector types available on request
- 7) Calibrated in µm on demand
