Temperature range |
Controlled environment (-10°C/+60°C) | ||
| Cable parameters |
Jacket material |
OFNG-LS
|
|
|
Cable construction |
Bare ribbon | ||
|
Outer diameter |
2mm | ||
|
Fiber count |
96 | ||
|
Fiber type |
MMF OM3
|
||
| Connector parameters | MT ferrule | MXC | |
|
Compliance |
US CONEC standard |
US CONEC standard | |
|
Colour of housing
|
N/A |
Aqua | |
|
Colour of boot
|
N/A | N/A | |
|
Polish
|
Flat (PC) | N/A | |
|
Insertion Loss (@850nm)
|
<1,7dB per channel
|
<1,7dB per channel | |
| Identification | Label with unique serial number. | ||
| Packaging |
Each assembly in antistatic bag, bulk pack in cardboard box. |
||
- Product drawing
- Product drawing
- Product sheet
- Product sheet
- Product sheet
- Product sheet
- Product sheet
- Product sheet
- Cable Datasheet
- Cable Datasheet
- Packaging specification
- Optical Connector cleaning procedure
- Polarities
- Cable installation
- Cable installation
- Cable installation
|
Description |
Partnumber/Ordering code |
| 6x MXC(R) – 8x MT(F) 96F OM3 Shuffle Cross-Connect |
SCC-MXCR-MTF-96-53 |
