Product Specification
| Performance properties |
Strain range |
±2500μɛ
|
|
|
Accuracy (guaranteed) 1) |
<0.50% FS 3) | ||
|
Accuracy (typical) 1) |
<0.23% FS 3) | ||
|
Precision (guaranteed) 2) |
<0.25% FS 3) | ||
|
Precision (typical) 2) |
<0.15% FS 3)
|
||
| Temperature compensation | Integrated 4) l | ||
|
Temperature accuracy 1) |
< 1 °C | ||
|
Temperature precision 2) |
±0.3°C
|
||
|
Operating Temperature range |
-20°C to +60°C
|
||
| Physical properties |
Housing material |
0.3-0.5mm thick GFRP
|
|
|
Anchoring distance |
n/a | ||
|
Dimensions (without cable) 1) |
Variable length (min 50mm) x 15 x 0.3-0.5 mm | ||
|
Weight (without cable) |
Around 30 g per FBG | ||
|
Cable type |
900mm PTFE/PEEK tubing
|
||
| Cable length 2) | 1mtr | ||
| Cable Bend Radius (dynamic) |
20 mm
|
||
| Cable Bend Radius (static) |
10 mm
|
||
|
Connector type 3) |
FC/APC | ||
|
Mounting method |
Glue | ||
| Packaging | Cardboard box with dimensions: 370x290x45mm | ||
| Quality Statement | DSS-01 sensor is compliant with IEC 61757:2018, IEC 61757-1-1:2020 and IEC 61757-2-1:2021. All sensors are 100% tested and calibrated at SYLEX. Sensor is manufactured according to ISO 9001:2015 and ISO 14001:2015 | ||
Notes:
- 1) Accuracy is established for each individual sensor under laboratory conditions and it includes hysteresis, non-linearity and repeatability of the sensor
- 2) Precision is established on a batch basis and it includes hysteresis, non-linearity, repeatability and reproducibility of the sensor
- 3) FS: full scale range
- 4) Optional
- 5) For further dimensions details see the product drawing
- 6) Cable length is extendable on request
- 7) Other connector types available on request
