Product Specification
| Performance properties |
Temperature range |
-20 up to +350°C or up to +600°C4)
|
|
|
Temperature accuracy |
1% FS3) | ||
| Temperature accuracy (typical)1) | <0.8% FS3) | ||
| Temperature precision | ±0,45% FS3) | ||
| Temperature precision (typical)2) | ±0,35% FS3) | ||
| Temperature resolution | 0,1°C | ||
| Ingress Protection rating | IP 68 | ||
| Operating Temperature range | -50°C to +600°C | ||
| Physical properties |
Housing material |
SS304 – 1.4301
|
|
| Dimensions (without cable)5) | Variable (OD 2mm) | ||
| Weight (without cable) | 170g | ||
| Cable type | SS tubing / 3mm Dyneema reinforced cable | ||
| Cable length6) | 1.5mtr | ||
| Cable Bend Radius (dynamic) | 40mm | ||
| Cable Bend Radius (static) | 30mm | ||
| Connector type7) | FC/APC | ||
| Packaging | Custom packaging depending on the total length | ||
| Quality Statement | HTA-01 sensor is compliant with IEC 61757:2018 and IEC 61757-2-1:2021. All sensors are 100% tested and calibrated at SYLEX. Sensor is manufactured according to ISO 9001:2008 and ISO 14001:2004 | ||
Notes:
- 1) Accuracy is established for each individual sensor under laboratory conditions and it includes hysteresis, non-linearity and repeatability of the sensor.
- 2) Precision is established on a batch basis and it includes hysteresis, non-linearity, repeatability and reproducibility of the sensor.
- 3) FS: full scale range
- 4) Can be extended to range from -50 up to +600°C
- 5) For further dimensions details see the product drawing.
- 6) Cable length is extendable on request.
- 7) Other connector types available on request.
