Performance properties	Measured parameter	relative or absolute pressure 1)
	Pressure range	1-20 bar 2)
	Operating temperature range	-20°C to +60°C
	Resolution	0.1% FS 3)
	Accuracy	<1% FS 3)
	Precision	<0.5 % FS 3)
	Pressure sensitivity (1bar range)	4pm/1mbar
	Operating humidity range	0 – 95 % Relative Humidity
	Burst pressure	up to 150 % FS 3)
	Measurement rate	up to 100 measurements/second 2)
	Occupied bandwidth	〜12nm
	Ingress Protection rating	IP 68
Physical properties	Housing material4)	Stainless steel SS316L
	Dimensions without cable	Ø30 x 164 mm
	Weight (without cable)	550 g
	Cable type5)	7mm reinforced cable / 6mm PA12 (Nylon) tube
	Cable length6)	2mtr
	Cable Bend Radius (dynamic)	80 mm
	Cable Bend Radius (static)	70 mm
	Connector type7)	FC/APC
	Pressure inlet thread	G1/8
	Porous stone 8)	Optional – upon request
Packaging	Cardboard box with dimensions: 370x290x45mm
Quality Statement	The sensor is compliant with IEC 61757:2018 and IEC 61757-2-1:2021. All sensors are 100% tested and calibrated at SYLEX. Sensor is manufactured according to ISO 9001:2008 and ISO 14001:2004

Notes:

¹⁾Absolute pressure sensor available upon request ²⁾Standard configuration includes pressure ranges: 1, 4, 7, 10, 15, and 20bar ³⁾ FS: full-scale range ⁴⁾ Other housing materials are available on request ⁵⁾ For liquid level monitoring, the LLS-01 will be equipped with a cable with air channels connected to the sensor through a bottle splice ⁶⁾ Cable length is extendable on request ⁷⁾ Other connector types available on request ⁸⁾ MG40 316 sintered stainless steel (high permeability)
