Product Specification
| Performance properties |
Temperature range1) |
-50°C up to +250°C
|
|
|
Temperature accuracy |
1% FS4) | ||
|
Temperature accuracy (typical)2) |
0.8% FS4) | ||
|
Temperature precision |
±0,30% FS4) | ||
|
Temperature precision (typical)3) |
±0,20% FS4)
|
||
| Temperature resolution | 0,1°C | ||
| Temperature sensitivity | 11 pm/°C | ||
| Ingress Protection rating | IP 65 | ||
| Physical properties |
Housing material |
Stainless steel SS316L and CW004A Cu-ETP
|
|
| Dimensions (without cable)5) | Ø34mm x 9.5mm | ||
| Weight (without cable) | 45g | ||
| Cable type | 3mm Stainless steel tubing / 3mm Dyneema tubing | ||
| Cable length6) | 2mtr | ||
| Cable Bend Radius (dynamic) | 30mm | ||
| Cable Bend Radius (static) | 15mm | ||
| Connector type7) | FC/APC | ||
| Mounting method | Direct surface mounting | ||
| Packaging | Cardboard box with dimensions: 370x290x45mm | ||
| Quality Statement | STS-04 sensor is compliant with IEC 61757:2018 and IEC 61757-2-1:2021. All sensors are 100% tested and calibrated at SYLEX. Sensor is manufactured according to ISO 9001:2008 and ISO 14001:2004 | ||
Notes:
- 1) Temperature resistance up to 300°C. Calibration range to be agreed with client based on the project requirements.
- 2) Accuracy is established for each individual sensor under laboratory conditions and it includes hysteresis, non-linearity, and repeatability of the sensor.
- 3) Precision is established on a batch basis and it includes hysteresis, non-linearity, repeatability and reproducibility of the sensor.
- 4) FS: full scale range
- 5) For further dimensions details see the product drawing.
- 6) Cable length is extendable on request.
- 7) Other connector types available on request.
